Hikvision 16 Channel DVR DS-7616HUHI-F2-N

  • £373.20

  • Ex Tax: £311.00
 (0 reviews)
  • Brand: HIKVISION
  • Product Code: DS-7616HUHI-F2-N
  • Availability: In Stock

Available Options

- +

Hikvision 16 Channel DVR DS-7616HUHI-F2-N

Download:


Features and Functions

  • H.264 ,H.264+& Dual-stream video compression
  • Support  HD-TVI, IPC, AHD and analog cameras with adaptive access
  • Support Cloud storage(One Drive, Google Drive or Drop Box)
  • HDMI and VGA output can be configured simultaneous or independent. If simultaneous, up to 4K (3840 × 2160) resolution is supported; if independent, up to 1920 × 1080 resolution for VGA output and up to 4K (3840 × 2160) resolution for HDMI output
  • Long transmission distance over coax cable
  • Up  to 4/8-ch synchronous playback at 1080p resolution
  • Playback at up to 256X speed.

Video Input and Transmission

  • Connectable to HDTVI, AHD and analog cameras
  • Up to 8/16/32-ch 8MP IP cameras input for DS-7604/7608/7616HUHI-F/N
  • Long distance transmission over UTP and coaxial cable


Compression and Recording

  • One-key enable H.264+ compression to improve encoding efficiency by up to 50% and reduce data storage costs
  • Full Channel recording at 3MP


Video Output

  • Simultaneous HDMI/VGA output at up to 1920 × 1080 resolution for DS-7604HUHI-F1/N; for DS-7608/7616HUHI-F2/N, HDMI and VGA output can be configured simultaneous or independent. If simultaneous, up to 4K (3840 × 2160) resolution is supported. If Independent, up to 1920 x 1080 resolution for VGA output and up to 4K (3840 x 2160) resolution for HDMI output.
  • Independent CVBS output improves compatibility at the most possibility and serves as the aux output or live view output only


Storage and Playback

  • One or Two SATA interface (up to 6 TB capacity per HDD)
  • 4/8/16-ch synchronous playback up to 3MP resolution
  • Smart search for efficient playback
  • Supports 3rd party cloud storage (Dropbox, Google Drive, Microsoft One Drive)


Smart Function

  • Supports multiple VCA (Video Content Analytics) events for both analog and smart IP cameras
  • VQD (Video Quality Diagnostics)
  • Unlock pattern for device login for the admin and clear-text password available
  • GUID file can be exported for password resetting and imported for finding the forgotten password
  • Supports PTZ control via Omnicast VMS of Genetec protocol


Network & Ethernet Access

  • Hik Cloud P2P & HiDDNS (Dynamic Domain Name System) for easy network management
  • 1 gigabit Ethernet network interface (for DS-7608/7616HUHI-F2/N)
  • Output bandwidth limit configurable
DVR
Video Compression H.264+ / H.264
Analogue Video Input 16 Channel, BNC Interface (1.0Vp-p, 75Ω), Supporting Coaxitron Connection
Alarm Input/Output 16 / 4
HD TVI Input 1080p25, 1080p30, 720p25, 720p30, 720p50, 720p60, 3 MP
AHD Input 1080p25, 1080p30, 720p25, 720p30
CVBS Input Supported
IP Video Input 16 Channel (Up to 32-Channel), up to 8MP Resolution
Network Bandwidth 144 Mbps (incoming bandwidth: 76 Mbps)
Audio Compression G.711u
Audio Input 4-ch, RCA (2.0 Vp-p, 1 KΩ)
CVBS Output 1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480
HDMI / VGA Output VGA: 1-ch, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

HDMI: 1-ch, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz
Encoding Resolution 3 MP/1080p/720p/WD1/4CIF/VGA/CIF
Frame Rate Main stream:
3 MP@15fps;
1080p/720p/WD1/4CIF/VGA/CIF@25fps (P)/30fps (N)

Sub-stream:
WD1/4CIF@12fps;
CIF/QVGA/QCIF@25fps (P)/30fps (N)
Video Bit Rate 32 Kbps to 10 Mbps
Audio Output 1-ch, RCA (Linear, 1 KΩ)
Audio Bit Rate 64 Kbps
Dual Stream Supported
Stream Type Video, Video & Audio
Synchronous Playback 16 Channel
Network Protocols TCP/IP, PPPoE, DHCP, Hik Cloud P2P, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP™, HTTPS, ONVIF
SATA Interface 2 SATA Interface
HDD Capacity Up to 6 TB each disk
Network Interface 1, RJ45 10M/100M/1000M self-adaptive Ethernet interface
USB Interface Front panel: 1× USB 2.0

Rear panel: 1×USB 3.0
Serial Interface RS-485 (half-duplex)
Power Supply 12V DC
Consumption (Without HDD) ≤ 40 W
Working Temperature -10 ºC to +55 ºC (14 ºF to 131 ºF)
Working Humidity 10% to 90%
Dimensions (W x D x H) 380 × 320 × 48 mm (15 × 12.6 × 1.9 inch)
Weight (Without HDD) ≤ 2 kg (3.3 lb)
